Anchor Shackles Screw Pin Forged Alloy-G209
Anchor Shackles Screw Pin Forged Alloy-G209
Screw Pin Anchor Shackle
Anchor Shackles, Screw Collar Pin, Forged Alloy Steel, High Tensile Strength, Meet to US Federal Specification. G209
Anchor Shackles are supplied in hot dip galvanized finish or self coloured.
Working Load Limit permanently shown on every Anchor shackle.
Forged - Quenched and Tempered.
Capacities 1/3 thru 55 metric tons.
Fatigue rated
|
ITEM NO
|
Nominal
Size
|
Working
Load
Limit
|
Dimensions
(mm)
|
Weight
each
|
||||||||||
|
(in.)
|
(tons)
|
A
|
B
|
C
|
D
|
E
|
F
|
G
|
H
|
I
|
M
|
N
|
(kg)
|
|
|
AS0632
|
3/16
|
1/3
|
9.65
|
6.35
|
22.4
|
4.85
|
15.2
|
14.2
|
24.9
|
37.3
|
4.06
|
28.4
|
4.85
|
0.03
|
|
AS0832
|
1/4
|
1/2
|
11.9
|
7.85
|
28.7
|
6.35
|
19.8
|
15.5
|
32.5
|
46.7
|
4.85
|
35.1
|
6.35
|
0.05
|
|
AS1032
|
5/16
|
3/4
|
13.5
|
9.65
|
31.0
|
7.85
|
21.3
|
19.1
|
37.3
|
53.0
|
5.60
|
42.2
|
7.85
|
0.09
|
|
AS1232
|
3/8
|
1
|
16.8
|
11.2
|
36.6
|
9.65
|
26.2
|
23.1
|
45.2
|
63.0
|
6.35
|
51.5
|
9.65
|
0.14
|
|
AS1432
|
7/16
|
1-1/2
|
19.1
|
12.7
|
42.9
|
11.2
|
29.5
|
26.9
|
51.5
|
74.0
|
7.85
|
60.5
|
11.2
|
0.17
|
|
AS1632
|
1/2
|
2
|
20.6
|
16.0
|
47.8
|
12.7
|
33.3
|
30.2
|
58.5
|
83.5
|
9.65
|
68.5
|
12.7
|
0.33
|
|
AS2032
|
5/8
|
3-1/4
|
26.9
|
19.1
|
60.5
|
16.0
|
42.9
|
38.1
|
74.5
|
106
|
11.2
|
85.0
|
17.5
|
0.62
|
|
AS2432
|
3/4
|
4-3/4
|
31.8
|
22.4
|
71.5
|
19.1
|
51.0
|
46.0
|
89.0
|
126
|
12.7
|
101
|
20.6
|
1.07
|
|
AS2832
|
7/8
|
6-1/2
|
36.6
|
25.4
|
84.0
|
22.4
|
58.0
|
53.0
|
102
|
148
|
12.7
|
114
|
24.6
|
1.64
|
|
AS3232
|
1
|
8-1/2
|
42.9
|
28.7
|
95.5
|
25.4
|
68.5
|
60.5
|
119
|
167
|
14.2
|
129
|
26.9
|
2.28
|
|
AS3632
|
1-1/8
|
9-1/2
|
46.0
|
31.8
|
108
|
29.5
|
74.0
|
68.5
|
131
|
190
|
16.0
|
142
|
31.8
|
3.36
|
|
AS4032
|
1-1/4
|
12
|
51.5
|
35.1
|
119
|
32.8
|
92.5
|
76.0
|
146
|
210
|
17.5
|
156
|
35.1
|
4.31
|
|
AS4432
|
1-3/8
|
13-1/2
|
57.0
|
38.1
|
133
|
36.1
|
92.0
|
84.0
|
162
|
233
|
19.1
|
174
|
38.1
|
6.14
|
|
AS4832
|
1-1/2
|
17
|
60.5
|
41.4
|
146
|
39.1
|
98.5
|
92.0
|
175
|
254
|
20.6
|
187
|
41.1
|
7.80
|
|
AS5632
|
1-3/4
|
25
|
73.0
|
51.0
|
178
|
46.7
|
127
|
106
|
225
|
313
|
25.4
|
231
|
57.0
|
12.6
|
|
AS6432
|
2
|
35
|
82.5
|
57.0
|
197
|
53.0
|
146
|
122
|
253
|
348
|
31.0
|
263
|
61.0
|
20.4
|
|
AS8032
|
2-1/2
|
55
|
105
|
70.0
|
267
|
69.0
|
184
|
145
|
327
|
453
|
35.1
|
330
|
79.5
|
38.9
|
