Forged Drop Alloy Steel Weldless Master Link
Forged Drop Alloy Steel Weldless Master Link
Material: 40Cr alloy steel/ stainless steel
Surface: Powder plastified/Galvanized / self color/painted
Packing: Carton, iron pallet
Alloy Steel
Quenched & Tempered
Ultimate Lad is 4 times Working Load Limit
Customized requirements are welcome!
| Size | W.L.L. | DIMENSIONS (mm) | Weight | |||||
| (mm) | (kgs) | B | C | D | D | E | F | (kgs) |
| 18-13 | 6,400 | 75 | 135 | 18 | 13 | 54 | 25 | 1.16 |
| 22-16 | 8,000 | 90 | 160 | 22 | 16 | 70 | 34 | 2.22 |
| 26-18 | 12,800 | 100 | 180 | 26 | 18 | 85 | 40 | 3.36 |
| 32-22 | 20,000 | 110 | 200 | 32 | 22 | 116 | 50 | 5.02 |
| 36-26 | 32,000 | 140 | 360 | 36 | 26 | 140 | 65 | 9.94 |
| 45-32 | 40,000 | 180 | 340 | 45 | 32 | 150 | 70 | 18.91 |
| 51-32 | 50,000 | 190 | 350 | 51 | 42 | 150 | 70 | 23.3 |
| 51-38 | 60,000 | 190 | 350 | 51 | 38 | 170 | 75 | 25.8 |
| 57-40 | 80,000 | 200 | 400 | 57 | 40 | 170 | 80 | 39.25 |
